Quantity:
| MPN: | CFM-A238BJ-226-469-20 |
| Manufacturer: | Same Sky (Formerly CUI Devices) |
| Voltage – Rated: | 24VDC |
| Air Flow: | 117.7 CFM (3.30m³/min) |
| Noise: | 46.9dB(A) |
| Power (Watts): | 6 W |
| RPM: | 2600 RPM |
| Width: | 38.00mm |
| Fan Type: | Tubeaxial |
| Series: | CFM-A2BJ |
| Size / Dimension: | Square – 120mm L x 120mm H |
| Static Pressure: | 0.250 in H2O (62.3 Pa) |
| Bearing Type: | Ball |
| Features: | Auto Restart, Speed Sensor (Tach) |
| Termination: | 3 Wire Leads |
| Ingress Protection: | – |
| Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency: | CE, cURus, TUV |
| Description: | DC AXIAL FAN, 120 MM SQUARE, 38 |
| Detailed Description: | Fan Tubeaxial 24VDC Square – 120mm L x 120mm H Ball 117.7 CFM (3.30m³/min) 3 Wire Leads |
| Current Rating (Amps): | 0.250A |
| Voltage Range: | 21.6 ~ 26.4VDC |
| Material – Frame: | Polybutylene Terephthalate (PBT) |
| Material – Blade: | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp.: | 70000 Hrs @ 40°C |
