| MPN: | 109R0812S402 |
| Manufacturer: | Sanyo Denki |
| Voltage – Rated: | 12VDC |
| Air Flow: | 42.4 CFM (1.19m³/min) |
| Noise: | 34.0dB(A) |
| Power (Watts): | 2.16 W |
| RPM: | 3400 RPM |
| Width: | – |
| Fan Type: | Tubeaxial |
| Series: | – |
| Size / Dimension: | Square – 80mm L x 80mm H |
| Static Pressure: | 0.193 in H2O (48.1 Pa) |
| Bearing Type: | Ball |
| Features: | Locked Rotor Protection |
| Termination: | 2 Wire Leads |
| Ingress Protection: | – |
| Operating Temperature: | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency: | CSA, TUV, UL |
| Description: | SANYO DENKI DC FAN MOTOR |
| Detailed Description: | Fan Tubeaxial 12VDC Square – 80mm L x 80mm H Ball 42.4 CFM (1.19m³/min) 2 Wire Leads |
| Current Rating (Amps): | 0.180A |
| Voltage Range: | 6 ~ 13.8VDC |
| Material – Frame: | Plastic |
| Material – Blade: | Plastic |
| Lifetime @ Temp.: | 60000 Hrs @ 60°C |
