| MPN: | 9BMB24P2S01 |
| Manufacturer: | Sanyo Denki America Inc. |
| Voltage – Rated: | 24VDC |
| Air Flow: | 43.1 CFM (1.21m³/min) |
| Noise: | 59.0dB(A) |
| Power (Watts): | 16.8 W |
| RPM: | 5250 RPM |
| Width: | 33.00mm |
| Fan Type: | Blower |
| Series: | San Ace B97 |
| Size / Dimension: | Rectangular/Rounded – 97.1mm L x 95mm H |
| Static Pressure: | 2.450 in H2O (610.0 Pa) |
| Bearing Type: | Ball |
| Features: | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) |
| Termination: | 4 Wire Leads |
| Ingress Protection: | – |
| Operating Temperature: | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency: | cURus, TUV |
| Description: | FAN BLOWER 97.1X33MM 24VDC WIRE |
| Detailed Description: | Fan Blower 24VDC Rectangular/Rounded – 97.1mm L x 95mm H Ball 43.1 CFM (1.21m³/min) 4 Wire Leads |
| Current Rating (Amps): | 0.700A |
| Voltage Range: | 21.6 ~ 26.4VDC |
| Material – Frame: | Plastic |
| Material – Blade: | Plastic |
| Lifetime @ Temp.: | 40000 Hrs @ 60°C |
