| MPN: | OD1232-48HB01A |
| Noise: | 51.0dB |
| Air Flow: | 120.0 CFM (3.36m³/min) |
| Power (Watts): | – |
| Voltage – Rated: | 48VDC |
| RPM: | 3750 RPM |
| Termination: | 3 Wire Leads |
| Manufacturer: | Orion |
| Size / Dimension: | Square – 120mm L x 120mm H |
| Width: | 32.00mm |
| Static Pressure: | 0.420 in H2O (104.6 Pa) |
| Bearing Type: | Ball |
| Fan Type: | Tubeaxial |
| Features: | Speed Sensor (Tach) |
| Ingress Protection: | – |
| Operating Temperature: | -4 ~ 176°F (-20 ~ 80°C) |
| Approval Agency: | cURus, TUV |
| Weight: | – |
| Series: | OD1232 |
| Current Rating (Amps): | 0.180A |
| Voltage Range: | 24 ~ 55.2VDC |
| Material – Frame: | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Material – Blade: | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Lifetime @ Temp.: | 60000 Hrs @ 40°C |
| Detailed Description: | Fan Tubeaxial 48VDC Square – 120mm L x 120mm H Ball 120.0 CFM (3.36m³/min) 3 Wire Leads |
