| MPN: | OD1238-24LS |
| Noise: | 33.0dB |
| Air Flow: | 73.0 CFM (2.04m³/min) |
| Power (Watts): | 4 W |
| Voltage – Rated: | 24VDC |
| RPM: | 1950 RPM |
| Termination: | 2 Wire Leads |
| Manufacturer: | Orion |
| Size / Dimension: | Square – 120mm L x 120mm H |
| Width: | 38.50mm |
| Static Pressure: | 0.130 in H2O (32.4 Pa) |
| Bearing Type: | Sleeve |
| Fan Type: | Tubeaxial |
| Features: | – |
| Ingress Protection: | – |
| Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency: | cURus, TUV |
| Weight: | – |
| Series: | OD1238 |
| Current Rating (Amps): | 0.140A |
| Voltage Range: | – |
| Material – Frame: | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Material – Blade: | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Lifetime @ Temp.: | 65000 Hrs @ 45°C |
| Detailed Description: | Fan Tubeaxial 24VDC Square – 120mm L x 120mm H Sleeve 73.0 CFM (2.04m³/min) 2 Wire Leads |
